Lifeboat cranes is mainly used to move cargos, containers and other materials while the vessel is within a harbor or sheltered area. And it usually is mounted on surface type vessels.
| NameNAME | Model | ||||
| NMC113F | NMC0215F | NMC0316F | NMC0416F | NMC512F | |
| Max hoisting load | 0.98T | 2T | 3T | 4T | 5T |
| Slewing radius | 3-13M | 3.5-15M | 3.6-16M | 3-16M | 2.7-12M |
| Max. slewing angle | ≤330 | ≤330 | ≤330 | ≤330 | ≤330 |
| Hoisting speed | ≥15M/MIN | ≥15M/MIN | ≥15M/MIN | ≥15M/MIN | ≥10M/MIN |
| Slewing speed | 0.26R/MIN | 0.25R/MIN | 0.5R/MIN | 0.5R/MIN | 0.25R/MIN |
| Type/powerof electric motor | Y160L-4-H/15KW | Y160L-4-H/15KW | Y180L-4-H/22KW | Y180L-4-H/22KW | Y180L-4-H/22KW |
