Model | Dimensions | Capacity (pers. at 82.5 kg)
| Speed | Engine | Unloaded |
---|---|---|---|---|---|
NM60R (Outboard) | 6.00 x 2.30 x 0.87 m | 3-15P | 3P≥20 Knots | Mercury 60HP | 1175KG |
NM60R (Inboard) | 6.00 x 2.30 x 0.87 m | 3-15P | 3P≥20 Knots | BukH R210J Steyr SE164E40 Yanmar 4LHA-HTP SY 144C | 1734KG |
NM60R (Inboard) | 6.00 x 2.30 x 0.87 m | 3-15P | 3P≥33 Knots | BukH R270J Steyr SE236E40 | 1734KG |
Engine type | R210J/S270 |
Engine duty rating | C13 - High Speed Craft Commercial_2 |
Crankshaft power [hp(kW)] | 210 (154)/270 (199) |
Rpm@full load | 3800 |
Cylinders | In-line 4/V6 |
Displacement [L] | 2.2/3.0 |
Bore [mm] | 85.4/85 |
Stroke [mm] | 96/89 |
Compression ratio | 17.5:1 |
Injection system | Common rail direct injection (CRDi) |
Alternator [V -A] | 12V – 150A |
Electronic engine diagnostic | YES |
Max. torque @ rpm | 38 kg-m @ 3800/51 kg-m @ 3800 |
Dry Weight Bobtail [kg] | 280/334 |
Propulsion system | Shaft drive - Water jet |
Safe working load | 4000kg |
Type approval test load(6 time) | 24000kg |
Material | SUS |
This article is designed to provide the knowledge and skills to the rescue boat crew who safely carry out these duties. It can train personnel in the proper actions involved in taking command of, launching, and handling of a fast rescue craft. Read More
